X-701 Combo Pack Coaxial Type (Integrated Propulsion System ) Alpha 80A 135/280KV
$720.00
T-MOTOR X-701 Standard Integrated Propulsion provides reliable thrust, efficient power, and stability, perfect for UAVs in aerial missions.
Description
Detail Information
- Polymer propellers are not recommended for coaxial setups
- Free of complicated mounting process
- Turn-key system, perfect compatibility, superb cost performance
- Fast and convenient
Specifications
| Model | X-701KV135 | Lead Cable Length | 580mm |
| Dimension | 126.5*81.5*126.1mm | Arm Set Weight(Incl. Cable) | 1175g |
| Configuration | 24N28P | Shaft Diameter | IN:8mm OUT:8mm |
| Idle Current (24V) | 0.9A | Rated Voltage (Lipo) | 12S |
| Internal Resistance | 94mΩ | ESCRecommendation | ALPHA 80A 12S |
| Max. Power (180s) | 434W | PropellerRecommendation | P24*7.2 |
Technical Drawing
